Description:
5 Way Electrical wire spring lever connectors
Clear visible indication and a simple colour coded scheme make inspection and identification fool proof. There is an electrical test point in the base of the housing for checking the on/off supply.
Simply strip wire length at 10mm and insert into the connector and secure the lever then release the lever to remove the cable and re-use the connector.
Voltage: 240/440v
Strip length: 9 - 10 mm
Current: 32 A
Colour: Grey/Orange
Size: 5 way
For use with:
0.75mm - 2.5mm - Solid Cables
1.5mm - 2.5mm - Stranded Cables
0.08 - 4mm - Flexible Cables
Cables must be the same polarity i.e all lives or all neutrals etc.
Clear visible indication and a simple colour coded scheme make inspection and identification fool proof. There is an electrical test point in the base of the housing for checking the on/off supply.
Simply strip wire length at 10mm and insert into the connector and secure the lever then release the lever to remove the cable and re-use the connector.
Voltage: 240/440v
Strip length: 9 - 10 mm
Current: 32 A
Colour: Grey/Orange
Size: 5 way
For use with:
0.75mm - 2.5mm - Solid Cables
1.5mm - 2.5mm - Stranded Cables
0.08 - 4mm - Flexible Cables
Cables must be the same polarity i.e all lives or all neutrals etc.
