Fracarro MBJ2r3UU T2 Ενισχυτής Κεντρικής 5G – 223619

Code 223619

3 Inputs

3-input (III+DAB, UHF, UHF) multiband TV indoor amplifier with 20dB gain and up to 115dBμV output level on UHF band, separate amplification with independent level adjustment (20dB) for each input and low noise figure. T2 technology with UHF cut band for LTE 4G @790MHz and 5G @694MHz.

Technical chars

• Built-in 5G filter at 694MHz to minimise clutter in junction boxes compared to the use of an external filter.
• A.B.L.A. functionality. fRACARRO's exclusive system for maintaining the set output level constant even when the level of each input changes (independent A.B.L.A. circuits) with output level stabilisation even for high variations in the input TV signal and LED operation of the dedicated A.B.L.A. circuits.
• High shielding against LTE interference (LTE Free)
• Protective shell: the new switchboards are equipped with an ABS fireproof and flame retardant (Class V0) enclosure
• Prepared for mounting on a standard DIN rail with quick release.
• The dimensions of the MBJ EVO T2 have been designed so that they can be easily installed inside wall boxes.
• Very high efficiency switching power supply (>80%) and self-resetting short-circuit protection circuit.
• Selector for remote power supply on each input (100mA total).
• Power supply status LED.
• Faston for connection to TV system earth.
